主板 express uatx（或 v2m-p1）是 versatile express 系列中的第一款可用主板。它嵌在 uatx 大小的两件式漂亮塑料外壳内。活动式壳盖可以露出主板以便安装子板和连接测试设备。所有连接器和控制器都安装在后面板上。

此主板有两组子板牛角连接器。它必须始终与处理器子板 express 或软宏模型子板配对使用以提供主系统处理器。可以添加可选的逻辑子板 express 板以提供自定义 ip 开发和验证功能。

• 配备各种有用的外设接口
• 适用于 versatile express 子板的拖放式 usb 驱动器配置机制
• 功能强大的启动监视器程序可以配置子板并启动应用软件映像
• 单元预先装载了 debian linux 安装程序
• 可以通过 rs232 端口远程控制系统电源并重置信号
• 紧凑独立的系统，携带方便并适合进行展示或客户部署

the versatile express family development platform provides
an excellent environment for prototyping the next
generation of system-on-chip designs. through a range of
plug-in daughterboards hardware and software applications
can be developed and debugged.
the motherboard express atx is a motherboard especially
designed to support future generations of arm processors,
starting with support for the cortex -a9 processor. it
enables:
™
™
evaluation of new arm technology
system benchmarking
noperating system ports
ncustomer peripheral driver development
nearly software development

features
deliverables
nmicroatx formfactor
- use standard microatx case for expansion
nreduced size enclosure
- (w290mm x d260mm x h75mm)
nperipheral set compatible with versatile family
- eb, pb-11mpcore, pb-a8 and pbx
- program memory 128mb nor flash
nsimplified configuration of system
- usb flash drive to pc
- remote power cycling
- fast programming and configuration
- configuration file for system settings
- support for automated/remote operation
ndaughterboard support
- two daughterboards supported
(processor and fpga)
- axi master and slave links between
daughterboards
- pcie x8 link root complex* or endpoint
supported*
- multimedia interface:
- video* (165mhz pixel clock 1080p)
- audio* spdif and i2s 8 channels
npci-express slots for expansion
- two x4 slots with an x4 link implemented
- one x8 slot with an x4 link implemented
- one x16 slot with an x4 link implemented
nmotherboard in enclosure
n12v 60w 110-240v ac brick power supply
npower supply
- 60w 12v brick and atx plug-in module
- upgrade to atx psu if required for pcie
nversatile express support cd/dvd
nboot monitor software
- retarget of c i/o libraries
nself test software
- peripheral driver example
nos support*
- linux debian 2.6.28
- symbian to follow
- wince to follow
* features stated here will depend on the daughterboard used.
